TTL/RGB Interface

Think of the TTL/RGB interface as a "communication bridge" for electronic devices. They send video signals between your computer and display devices, allowing you to see images on the screen. Just as a painter mixes red, green, and blue to create a painting, this interface works in the same way by breaking down the colors of each pixel and sends them as separate colors to the display device. This means, every image we see, no matter how diverse in color, are actually produced by a mix of red, green and blue signals. Whether it's this text you're reading, a movie you're watching or a game you're playing - all of these rely on the work of the TTL/RGB interface. In short, TTL/RGB interface is a key technology that allows electronic devices to display images.

OLED Display Module Specifications

Wearable & Small Displays (0.95" - 2.06")

Size	Resolution	Interface	Brightness (nits)	Main Application
0.95 inch	120 x 240	SPI / I2C	350	Smart Band
1.20 inch	390 x 390	MIPI / SPI	400	Smart Watch
1.39 inch	454 x 454	MIPI	450	High-end Wearable
1.50 inch	128 x 128	SPI	300	Medical Device
2.06 inch	410 x 502	MIPI	500	Smart Watch / IoT

Industrial & Handheld Displays (3.92" - 8.0")

Size	Resolution	Interface	Brightness (nits)	Main Application
3.92 inch	1080 x 1200	MIPI	400	VR / AR Headset
5.00 inch	1080 x 1920	MIPI	450	Handheld Terminal
5.50 inch	1080 x 1920	MIPI	500	Smart Home Control
6.00 inch	1440 x 2880	MIPI	450	Industrial PDA
7.00 inch	1080 x 1920	MIPI	500	Vertical Handheld Device
7.00 inch	1280 x 800	LVDS	450	Industrial / Medical Monitor
8.00 inch	1200 x 1920	MIPI	500	Tablet / Smart Panel

IT & Laptop Displays (12.6" - 15.6")

Size	Resolution	Interface	Brightness (nits)	Main Application
12.6 inch	2560 x 1600	eDP	400	Premium Tablet
13.3 inch	1920 x 1080	eDP	400	Ultrabook / Laptop
14.0 inch	2880 x 1800	eDP	500	High-end Laptop
15.6 inch	3840 x 2160	eDP	400	Portable Monitor / Laptop
